AUTOMOTIVE / CUSTOM METAL PARTS
COMPONENT REFERENCEES-AU-003
Automotive Bushing
Precision machined bushing for automotive motor or mechanical support assemblies.
- Material
- Stainless steel / alloy steel
- Geometry
- Custom by drawing
- Order quantity
- 500 pcs Listed reference · discuss your quantity
Drawing review required
THE COMPONENT / THE REQUIREMENT
The fit is the feature.
Keep the bore, outside diameter and mating surfaces in the same manufacturing conversation. Review the component in its finished condition.
Explore CNC turningTechnical reference
ES-AU-003- Material reference
- Stainless steel / alloy steel
- Size / geometry
- Custom by drawing
- Surface options
- Polishing, passivation, deburring
- Listed order quantity
- 500 pcs
- Process
- CNC turning, drilling, grinding-ready finish
- Application
- Automotive metal support structure
The product record introduces available options. Your drawing and quotation define the supplied alloy, dimensions, finish and acceptance requirements.
CUSTOM COMPONENT MANUFACTURING
Custom metal bushing produced by CNC turning and finishing processes for stable assembly interfaces.
Component supply · Scope confirmed in your quotation
ENGINEER THE CONVERSATION / A BETTER RFQ
The details worth
getting right.
Use these review points with your drawing. No assumed tolerances or dimensions—only the requirements your component needs.
Control how the component locates.
Show shoulders, end faces, chamfers and any thread details. State the geometric and surface controls needed for the intended fit.
Agree the check before the batch.
Identify critical dimensions, the final condition and requested inspection evidence. Review sampling and reporting within the quotation.
INSIDE MANUFACTURING / REAL PROCESS PHOTOGRAPHS
From the cut
to the check.
Explore real manufacturing and inspection references. Define the route, critical features and documentation for your own part before production.
CNC TURNING / FEATURE STUDY
Every diameter has a purpose.
Explore the features that connect a turned component to its assembly.
WEKO / TURNED SHAFT / CHUCK, TOOL & WORKPIECE
ILLUSTRATIVE PROCESS STUDY / YOUR DRAWING DEFINES THE REQUIREMENTS
Define the surfaces that locate the part.
Mark critical diameters, shoulders and datums. Specify fits, form controls and surface finish where the component meets another part.
Review your fitsA thread needs more than a diameter.
Include thread standard, pitch, class and useful length. Dimension grooves, reliefs and edges, and identify any required thread gauges.
Review threads and groovesControl the inside and the outside together.
Define bore size, depth and finish. Add concentricity or runout requirements where needed, referenced to the functional datums.
Discuss your turned componentYOUR COMPONENT / YOUR NEXT STEP
Make the drawing
the starting point.
Tell us what you need for Automotive Bushing, or share a similar custom component. Include the quantity and the features that matter.
- 01
Current drawing or model
Add the revision, mating interfaces and any critical features.
- 02
Material, finish and quantity
State the alloy and treatment you need, plus initial and repeat quantities.
- 03
Timing and inspection
Include your target date and any reports needed for approval.
Useful answers.
Before the quote.
Can this reference be customized?+
Yes. Share the actual geometry, material, quantity and finished condition you need. The quotation defines the manufacturing scope; a reference image is not an approved production drawing.
Can I request a different sample or batch quantity?+
The current record lists 500 pieces. Drawing review required State your sample quantity and expected repeat demand so the appropriate route can be reviewed.
Does this include a complete motor or assembly?+
This offer concerns custom metal components. Complete motors, electronics, bearings and complete machine assemblies are not included in this component reference. Confirm the required component scope in your RFQ.
What should I send for a quotation?+
Send the current drawing or model, alloy, finish, quantity and timing. Mark critical dimensions and requested inspection records. An NDA can be discussed before confidential files are exchanged.
