Drone Gimbal Metal Component
Lightweight gimbal bracket and connector component for UAV structural systems.
- Material
- Aluminum alloy
- Geometry
- Custom by drawing
- Order quantity
- 100 pcs Listed reference · discuss your quantity
Prototype and batch quantity are confirmed after drawing review.
THE COMPONENT / THE REQUIREMENT
Every mounting face has a job to do.
Bring the mounting geometry, wall sections and functional surfaces into one review. The drawing defines the structural component you need.
Explore CNC millingTechnical reference
ES-DR-003- Material reference
- Aluminum alloy
- Size / geometry
- Custom by drawing
- Surface options
- Defined by drawing and application
- Listed order quantity
- 100 pcs
- Process
- CNC turning, milling and secondary machining
- Inspection
- Drawing-based dimensional review
The product record introduces available options. Your drawing and quotation define the supplied alloy, dimensions, finish and acceptance requirements.
CUSTOM COMPONENT MANUFACTURING
Precision metal part for gimbal or payload structure, with focus on lightweight machining and stable assembly interfaces.
Component supply · Scope confirmed in your quotation
